High Frequency Dewatering Machine Vibrating Screen

Basic Info

Running Track	Linear Vibrating Screen
Supporting Device	Coil Spring
Warranty	1 Year
Customized	Customized
Condition	New
After-sales Service	Perfect After-Sales Service and Use Guidance
Transport Package	Standard Export Plywood Case
Specification	Customizable
Trademark	TFZD
Origin	Xinxaing, Henan
HS Code	8474100000
Production Capacity	2000pieces/Years

Product Description

High Frequency Dewatering Machine Vibrating Screen
Product classification: fine screening series

TS series asphalt screen is also called the asphalt vibrating conveyor. The asphalt vibrating conveyor is widely used in medicine, chemical industry, feed, metallurgy, building materials, grain, food and other industries, and is used for grading and dehydration of various materials in varying degrees.

High Frequency Dewatering Machine Vibrating Screen

Product introduction

The asphalt screen is also called the asphalt vibrating conveyor. The asphalt vibrating conveyor is widely used in medicine, chemical industry, feed, metallurgy, building materials, grain, food and other industries for grading and dehydration of various materials to varying degrees. The machine supports the drainage screen basket on the four rubber springs of the frame, and uses two opposite rotating vibration motors to generate vibration. The frame is composed of steel pipe and channel steel by welding. The rubber spring has good damping effect, low noise and long service life. It can be used in pipeline operation to realize automation. The whole machine is beautiful and easy to use and maintain.Installation and commissioning

Install the upper bottom bracket, support spring and box in order. The static stiffness of rubber spring has been tested before leaving the factory, and the spring with the same (or similar) stiffness should be selected for different supporting parts of the same vibrating conveyor. During installation, place the rubber spring on the lower support seat, make the boss on the support seat enter the inner hole of the spring, and then lift the box, so that the inner hole of the rubber spring is aligned with the boss of the support plate, vertically drop the box and place it on the rubber spring. At this time, the height of the rubber spring at each support point should be consistent, and the error should not be greater than 2mm.
The connection of all parts of the vibration conveyor must be firm and reliable, all bolts must not be loose, all parts must not have any abnormal sound, and the small gap between the vibration part on the vibration conveyor and the surrounding fixtures is 30-50mm.

Maintenance and operation

Before starting the vibrating conveyor, check whether there are obstacles hindering the operation of the screen machine around and whether the connecting bolts are fastened, especially the fixing bolts of the vibrating motor, support seat and screen plate should be tightened again. Check whether the rotation directions of two vibration motors are opposite. If the rotation directions are the same, change the power wiring of one motor to make the rotation directions of two motors opposite. After 4 hours of continuous operation, measure the bearing temperature, which shall not exceed 75 ºC. Before stopping the vibrating conveyor, the feeding shall be stopped first, and the screen surface shall be stopped after the materials have gone. After parking, the materials and sundries on the screen surface shall be cleaned in time. The vibration motor shall be filled with special oil every 2 months.

High Frequency Dewatering Machine Vibrating Screen

Be careful:
1. The asphalt vibrating conveyor is non-standard equipment, which can be designed and customized according to the actual needs of customers and field requirements.
2. Tianfeng Vibrating Machinery reserves the right to modify all technical data and dimensions. If the real object is inconsistent with the design in the text, the real object shall prevail, and Xinxiang Tianfeng Vibrating Machinery Equipment reserves the right to interpret.

About Transportation

After you place the order and pay the deposit, we will start to arrange the production and contact the ocean freight transportation agency to reserve the position. Two days before the end of production, you need to complete the final payment. Then, we inform the ocean cargo transportation agent company that it is ready to come to the factory to pull the goods to the port. On the day of delivery, we will send the customer the factory video and pictures, and mark the corresponding English name of each product and product parts with a marker to prevent the customer from not knowing what each part is after receiving the goods. At the same time, we will put the English version of the product instructions in the cargo box. We generally select freight forwarders with preferential prices for customers to deliver goods for you. The shipping method can be FOB or CIF. You can also choose EXW, and then contact the goods agent company yourself.FAQ
1. Who are we?
Our headquarters is located in Henan, China, and our factory was established in 2002. At present, there are more than 100 workers, technical engineers, foreign trade sales personnel, and administrative personnel. The factory covers an area of more than 2000 square kilometers and is mainly engaged in vibrating screening and conveying and feeding equipment.
2. How do we guarantee the quality?
Always provide pre-production samples before mass production; Always carry out a final inspection before shipment.
3. What can you buy from us?
You can purchase a vibrating screen, roller screens, rotary screens, vacuum conveyors, mixer, and customized vibrating machinery and conveying equipment in our factory.
4. What are our strengths?
As one of the old enterprises in the screening industry, Tianfeng has provided a large number of screening equipment and systems at home and abroad. Mass production, rapid delivery, stable quality, affordable price, and excellent after-sales service have become the symbols of Tianfeng.
5. What services can we provide?
Accepted delivery conditions: FOB, CFR, CIF, EXW, CIP, FCA, CPT, DDP, express;
Accepted payment currency: USD, EUR, RMB;
Type of payment accepted: telegraphic transfer, letter of credit, express remittance, credit card, PayPal, Western Union remittance, cash, custody;
Oral: English, Chinese, French.
6. What information do we need to help you choose a perfect machine?
-Name and characteristics of raw materials.
-Purpose of use: remove impurities, filter, and grade.
-Processing capacity: kg/h, L/h.
-Raw material size: (mesh or mm).
-How many floors do you need?
-Voltage, frequency, phase (single-phase or three-phase) Note: You'd better send us the relevant pictures or materials you want to filter, which can ensure that we recommend the appropriate machine for you.
